Horne H40 thermostatic mixing valve

Horne 40 Thermostatic mixing valve (dead leg version)

Check valves with inlet connections male screwed 1 1/2 inch B.S.P. (DN40) and outlet connection female tapped 1 1/2 inch B.S.P. (DN40) with dial thermometer. Ranges of temperature adjustment available:

• 15°C to 32°C
• 32°C to 52°C
• 45°C to 62°C
• 58°C to 80°C

In bronze finish.

Applications

• Thermostatic mixing valve to supply groups of taps or showers where large flow rates required.  For sizing a TMV for group mixing applications use our simple Valve Selector Tool
• domestic hot water supplies from large combination boilers
• hot water for process applications

Features

• Highly accurate temperature control across full range of flow rates
• Robust and reliable
• Ease of maintenance
• Patented design: high flow - low flow functionality

Standards and Approvals

• All materials in contact with water are WRAS approved.
• All HORNE products are manufactured under our Quality Management System to BS EN ISO 9001:2008. Certificate No. FM01224
